The Steel Patio Cover
Specialty Steel Backyard
Accessories
 Perfect for your house or trailer
home. Protect your Car, Boat or Patio Furniture. Provides secure
protection from the elements with a 15 year warranty. We recommend that
you pour a concrete base or use concrete footings to anchor the Patio
Cover. Everything is included to assemble the Patio Cover, all hardware and an
assembly video. we make it easy with pre-cut and pre-drilled parts.
■ Size: 10' x 10' or 10' x
20' (Rounded to nearest foot)
■ Height: 102" Inside
clearance
■ Front support poles are 4
x 4 - .026" thick vinyl coated galvanized steel
■ Snow load rating on this unit is 19lbs. / sq. ft.
■ House wall mount starts at 102" (8'6") and can go up to 108" (9'). If you wish to go lower than 102"
on the back wall you will need to adjust the front poles by the amount you lower the back wall
mounting rail. You will need a metal blade and saw to accomplish this.
■ Mounting rail is 2 1/2" wide.
■ Minimum of 6" is required above any door or window.
■ Vinyl coated "stepped"
galvanized steel
construction - .024" thick
■
Strength & Beauty
■ Maintenance Free
■ White only
■ Installation Video Included
■ 15 year limited warranty
■ Recommended concrete slab base or concrete footings
■ Easy assembly - All parts pre-cut & pre-Drilled
■
Prices are in US$
for Delivery Included in the contiguous USA
To our Florida customers...
CLICK HERE
*Due to Florida's 125mph wind load restrictions, it should be noted that this building cannot be made to conform to many South Florida building codes.
|
Model |
Size |
Credit
Card
Price $US |
Delivery Included
NO TAXES
No Handling
No Silly Fees! |
|
PC1010 |
10'
(projection)
x 10' |
$632.94 |
|
PC1020 |
10'
(projection)
x 20' |
$1032.94 |
|
Specifications |
Interior Dimensions |
Slab Size |
|
Model |
Size |
Sq. ft. |
Cu. ft. |
Weight |
Width |
Depth |
Height |
Width |
Depth |
|
PC1010 |
10'x10' |
99' |
848' |
251 lbs. |
119" |
119 ¼" |
102" |
123" |
130 ¼" |
|
PC1020 |
10'x20' |
197' |
1692' |
444 lbs. |
119" |
238" |
102" |
123" |
249" |
Obtaining necessary
permits is the sole responsibility of the purchaser. Customers agree
to hold ScreenHouses Unlimited and the manufacturer free of any
liability for improper installation,
maintenance and repair.
|
or
Save
Money - Do It Yourself
We eliminate security
risks! Place your order with a live person! ■■■ 1.800.922.4760
